Momentary right angled illuminated tact switch

A momentary right angled illuminated tact switch is a type of switch used in electronic circuits. It has a right angled design, which allows it to be mounted on PCBs in tight spaces. The switch is also illuminated, allowing users to see its operation in low light conditions.

The switch is a momentary type, which means it only makes contact when it is pressed down. This makes it suitable for use in applications where the user needs to trigger a circuit for a short amount of time. Examples of applications include keyboards, game controllers, and remote controls.

The switch is designed to have an extended operational life, with an estimated lifespan of up to 1 million cycles. This makes it suitable for use in products that require frequent button presses, such as gaming keyboards.

The switch has a clear cap that provides illumination. The cap can be customized to produce different colors of light, such as red, green, or blue. The switch can also be designed to have a bi-color LED, allowing two different colors of light to be produced by the same switch.

The switch has a force rating of 160 gf, which means it requires a moderate amount of force to activate. This ensures that accidental activation is minimized, while still allowing the user to easily trigger the switch when needed.

The switch has a contact resistance of less than 100 mΩ, which ensures that electrical signals are transmitted efficiently between the switch and the circuit it is connected to. This is important, as even small amounts of resistance can impact the performance of a circuit.

The switch has a voltage rating of 12 V DC, which means it can be used with most electronic circuits that operate at low voltages. The switch is also rated for an operating temperature range of -40°C to +85°C, which makes it suitable for use in harsh environments.

In conclusion, a momentary right angled illuminated tact switch is a reliable and durable component used in electronic circuits. Its small size and right-angled design make it easy to mount in tight spaces, while its illumination allows users to operate it in low light conditions. With its extended operational life, customizable illumination, and low contact resistance, it is an ideal choice for a wide range of applications.
