Momentary right angle illuminated led button switch

Momentary right angle illuminated LED button switches are one of the most common types of switches used in electronics. These switches are used to control various functions in electronic devices such as laptops, computers, and gaming consoles. These switches are also used in industrial applications where operator safety is a top priority.

The momentary right angle illuminated LED button switch is designed to turn on and off when pressure is applied to the button. The button has a spring mechanism that helps to keep it in the off position when it is not being pressed. The LED indicator helps the user to see if the switch is on or off in low light conditions.

The right-angle layout of the switch allows it to be mounted at a 90-degree angle to the printed circuit board (PCB). This allows the switch to be mounted in tight spaces, making it ideal for use in compact electronic devices.

The switch consists of a plastic housing that contains an LED, a button, and a metal contact. The housing is typically made from a high-temperature plastic, which can withstand high temperatures and protect the internal components of the switch.

The LED is a low-power, energy-efficient light that is used to indicate the status of the switch. The LED can be in a variety of colors such as red, green, or blue, depending on the application.

The button is typically made from a high-quality metal such as brass or stainless steel. The button has a spring mechanism that helps to keep it in the off position when it is not being pressed. The metal contact is located inside the housing and is used to complete the electrical circuit when the button is pressed.

The switch is designed to be used with a PCB. The PCB is used to connect the switch to other electronic components in the device. The switch is soldered onto the PCB using a high-temperature solder.

In conclusion, momentary right angle illuminated LED button switches are an essential component of modern electronics. These switches are designed to be energy-efficient, compact, and reliable. They are used in a variety of applications, including consumer electronics, industrial equipment, and automotive applications. With their energy-efficient design, low power consumption, and small size, these switches are likely to remain a popular choice in the electronics industry for many years to come.
