DIP SWITCH
4 Way DIP Switch
DP Series is 4 Position Dip Switch. This dip switch offers a variety of positions options. Stable quality and popular in configure computer peripherals industry. Besides, it uses PCB terminal for quick connection and easy assemble. Red and blue color are available.Their name comes from having the same shape and array of terminals found in integrated circuits (dual inline package), thus abbreviated to DIP.
Rating: 25mA 24VDC
Gap Distance: 2.54mm
Switch Function: OFF-ON
Operating Temperature: -25℃~+70℃
Operating Force: 8N Max
Installation Mode: PCB
Electrical Life: 2.000 Cycles
Posi No: 2,3,4,5,6,7,8,10,12
Contact Resistance: ≤500mΩ
Insulation Resistance: ≥100MΩ
Dielectric Strength: 500VACmin
